| Keyboard | 88 keys with Ivory Touch, Responsive Hammer II (RHII) action with Let-Off and 3 Sensors |
|---|
| Piano Sounds | Concert Grand 1/2, Studio Grand 1/2, Mellow Grand 1/2, Modern Piano, Rock Piano |
|---|
| Other Sounds | E-Piano x 4, Orgel x 4, Harbsi/Mallets x 4, Strings/Choir x 8, Bass x 4 |
|---|
| Sound Source | Progressive Harmonic Imaging™ (PHI) with 88 key sampling |
|---|
| Polyphony | max. 256 Notes |
|---|
| Virtual Technician | Voicing, String Resonance, Damper Resonance, Damper Noise, Fall-back Noise, Key-off Effect, Hammer Delay Temperaments, etc. |
|---|
| Reverb | Room, Lounge, Small Hall, Concert Hall, Live Hall, Cathedral - each with Depth and Time |
|---|
| Effekts | Stereo Delay, Ping Delay, Triple Delay, Chorus, Classic Chorus, Tremolo, Classic Tremolo, Auto Pan, Classic Auto Pan, Phaser, Rotary und 4 Kombinationseffekte - each with Dry/Wet, Time, Speed, Feedback, High Damp, Depth (Parameters depend on effect) |
|---|
| Amp Simulator | S.Case I, S.Case II, L.Cabinet - each with Drive, Level, EQ Low, EQ High |
|---|
| Dual-Mode | yes, with balance |
|---|
| Split-Mode | yes, with balance and free assignable split point |
|---|
| Accompaniment | 100 rhythms (x 2 variations), 4-part accompaniment, 100 preset chord sequences, Rhythm Volume, Auto Fill-in, One Finger Ad-lib, ACC Mode, Preset Chord, Rhythm Parts Select |
|---|
| Touch Control | Light+, Light, Normal, Heavy, Heavy+, Off (Constant), User 1, User 2 |
|---|
| Other Functions | 28 Registration Memories, Key/Song Transpose, Equaliser (incl. User EQ), Wall EQ, Speaker Volume, Phones Volume, Line Out Volume, Audio Recorder Gain, Tuning, Damper Hold, Four Hands, User Memory, Factory Reset, Lower Octave Shift, Lower Pedal On/Off , Split Balance, Layer Octave Shift, Layer Dynamics, Dual Balance, MIDI Channel, Send PGM#, Local Control, Transmit PGM#, Multi-timbral Mode, Channel Mute, Auto Power Off , Speakers On/Off |
|---|
| Recorder | Internal: MIDI 10 Songs, 2 Tracks – max. 90000 notes; USB Memory: MP3/WAV Recording and Playback, A-B Loop |
|---|
| USB Functions | Playback: MP3, WAV, SMF; Record: MP3, WAV; Other: Convert Song to Audio, Load Internal Song, Save Internal Song, Save SMF Song, Load Registration, Save Registration, Rename File, Delete File, Format USB |
|---|
| Metronome | Beats: 1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8; Tempo: 10-400 BPM |
|---|
| Demo Songs | 27 |
|---|
| Pedals | F10H Sustain Pedal with Half-Damper function included. Also available as option: double pedal F-20 or the 3 pedal unit F301 (in combination with HM-4 stand only). |
|---|
| Display | 16 x 2 character (LCD) |
|---|
| Jacks | MIDI (IN/OUT), USB to Host, USB to Device, LINE IN STEREO, LINE OUT (L/MONO, R), DAMPER (F-10H only), DAMPER/SOFT (F-20 only), PEDAL (F-301 only), Headphones x 2, AC-Adapter PS-154 |
|---|
| Speaker | 2 x (8x12)cm with Bass-Reflex-System, on/off switch |
|---|
| Output Power | 2 x 15 Watts |
|---|
| Size (cm) | 136,2 x 36,1 x 14,9 |
|---|
| Finish | Gloss Black or Ivory White |
|---|
| Weight (kg) | 22 |
|---|
| Optional Accessories | Designkit: Stand HM-4 with acrylic music rack; 3 pedal unit: F-301 to be mounted on HM-4 stand only |
|---|
