DB Technologies DVXD15HP 1400W 15" Active Speaker
Brand
D B TECHNOLOGIES
A two-way system featuring 15“/1.4“ speakers, the DVX D15 HP is the enclosure of choice for use as a fullrange FOH speaker or a powerful drum monitor.
It delivers punchy, assertive bass response without requiring an added subwoofer. Its integrated, high-performance digipro G2 digital power amp delivers very high sound pressure levels, exceedingly dynamic response, and tight, clean low-end response.
Loaded with high quality speakers, it provides premium audio performance with maximum reliability and minimum power compression.
A 1.4” driver with a 2,5” voice coil designed to handle highest loads renders vocals with a powerful, assertive punch, easily throwing signals across medium-to-longer distances.
The housing’s multifunctional design incorporates rigging points and a slanted panel serving monitoring purposes.
The onboard controller even provides a special monitor setup that specifically adapts the enclosure’s performance for use as a monitor.
It also serves as a controller for an active equalizer, x-over, limiter, and phase and delay time alignment.
The DVX D15 HP is the perfect match for DVA Series subwoofers
It also serves as a controller for an active equalizer, x-over, limiter, and phase and delay time alignment.
The DVX D15 HP is the perfect match for DVA Series subwoofers
Product Specs
Speaker Type
2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]
49 - 20.000 Hz
Frequency Response [+/- 3dB]
57 - 19.000 Hz
Max SPL
132 dB
HF
1.4 "
Voice Coil HF
Titanium 2.5 "
Directivity
60x40 °
Horn
CD Horn Aluminium
Rotatable Horn
YES
LF
15 "
Voice Coil LF
3.5 "
Amplifier
Amp Technology
Digipro® G2
Amp Class
Class D
Power RMS
700 W
Peak Power
1400 W
Cooling
Convection
Processor
Controller
DSP 24 Bit/48 kHz
System Presets
FOH, Monitor
Limiter
RMS, Peak. Thermal, Multiband
Crossover Frequency MF-HF
1320 Hz
Slope MF-HF
24 dB/Octave
Mechanics
Housing
Multiplex plywood
Housing Design
Multifunctional
Angles Up
Monitor use 45 °
Rigging Points
6x M10
4x Quick-Relase Pins
4x Quick-Relase Pins
Flytracks
3x on top
3x on bottom
3x on bottom
Width
430 mm (17.2 in)
Height
690 mm (27.6 in)
Depth
450 mm (18 in)
Weight
30.3 kg (66.8 lbs)
| Manufacturer | D B TECHNOLOGIES |
|---|
