Solid State Logic X-Desk
16-channel Compact Analog Mixer with 100mm Faders, Monitoring Section, Dim and Cut Buttons, Cascade Capability, and Rackmount Option
The Solid State Logic X-Desk 16-channel analog mixer puts the features, functionality and great sound of SSL's amazing AWS 900+, Duality, and Matrix consoles into a compact, easy-to-transport (and road-tough) chassis. Handcrafted in the UK, the X-Desk includes a 16-channel SSL SuperAnalogue summing mixer and a compact audio hub, along with smooth 100mm faders, premium monitoring functionality, and the kind of insert options and pro-level metering you've come to expect from SSL products. Rack ears are included, so you can easily make the X-Desk the heart of your portable rig.
Features
- Eight dual input mono line channels -16-channel mixdown
- Eight insert send/returns on channels
- Stereo cue and two mono auxiliary sends
- Cascade with X-Rack and other X-Desks for bigger systems
- Talkback functionality for artist communication
- Dim and Cut buttons
- Independent main and alternate stereo monitor outputs
- SSL stereo mix bus with external summing and Inserts
- Two stereo returns with level, pan and bus assignment
- iJack front panel input for portable playback devices
- High-quality internal PSU
- D-Sub channel I/O connection for studio integration
- 19" rackmount ears included
Product Specs
| Type | Analog |
|---|---|
| Channels | 8 |
| Inputs - Line | 1 x DB25 (Line), 1 x DB25 (Alt) |
| Inputs - Other | 1 x 1/8" (iJack) |
| Outputs - Main | 2 x XLR (Main), 2 x XLR (Alt) |
| Outputs - Direct | 1 x DB25 (CH 1-8) |
| Outputs - Other | 1 x DB25 (Centre: Mix, Cue, FX 1 &2) |
| Headphones | 1 x 1/4" |
| Send/Return I/O | 1 x DB25 (Insert Send), 1 x DB25 (Insert Return), 1 x DB25 (Cen In: Mix, Cue, FX 1/2), 1 x DB25 (Cen Out: Mix, Cue, FX 1/2) |
| Aux Sends | 2 x FX |
| Busses/Groups | Cue/Mix |
| Faders | 8 x 100mm |
| Channel Inserts | Yes |
| Talkback | Yes |
| Rackmountable | Yes |
| Height | 4.75" |
| Width | 17.1" (19" w/Rack Ears) |
| Depth | 12.25" |
| Weight | 10.5 lbs. |
| Manufacturer Part Number | 729712X1 |
