Pioneer DJM 750 4-Channel Mid-Range Digital Mixer Black
Brand
PIONEER
Delivering breath-taking scope for creativity, the DJM-750 takes FX manipulation and software synergy to new levels.
Delivering breath-taking scope for creativity, the DJM-750 takes FX manipulation and software synergy to new levels. The DJM-750 combines our latest audio and FX technology in an attractively priced 4-channel mixer. The mixer boasts 13 Beat FX with a dedicated Level/Depth knob for tactile control of the wet/dry mix.
The DJM-750 inherits the same 32-bit digital signal processor as our club-standardDJM-900NXS and a built-in 24-bit/96 kHz USB sound card, while 3 sampling rates makes it perfect for production and recording.
Features
| MIDI Control | Full assignable MIDI controls |
|---|---|
| P-LOCK Fader Caps | Yes |
| Auto Standby |
Product Specs
| Width | 320 mm |
|---|---|
| Height | 108 mm |
| Depth | 376 mm |
| Weight | 7.6 kg |
| Rack Mount | Yes |
| Frequency Range | 20 - 20,000 Hz |
| Sampling Rate | 96 kHz |
| A/D Converter | 24 bit |
| D/A Converter | 24 bit |
| S/N Ratio Line | 106 dB |
| Crosstalk Line | 82 dB |
| Distortion | < 0.004 % |
| Headroom | 19 dB |
| Power Consumption | 30 W |
Master
| Master Balance | Yes |
|---|---|
| Stereo/Mono Switch | Yes |
| Frequency Filter | Yes |
| Level Meter Size | 15 segment |
| Master Out Attenuator | Yes |
Channels
| EQ/ISO | 3 band |
|---|---|
| ISO Range | –26 dB ~ +6 dB |
| Level Meter Type | Individual |
| Level Meter Size | 15 segment |
Performance Control
| Channels | 4 |
|---|---|
| Sound Colour FX |
|
| Beat FX |
|
| FX Frequency | Yes |
Effect/Sampler
| 3-Band Isolator | Yes |
|---|---|
| Auto BPM Counter | Yes |
| Effect Level & Depth Volume | Yes |
| MIDI Global Clock | Yes |
| Roll Down | Yes |
| Roll Up | Yes |
| Roll Sampler (Fwd) | Yes |
| Roll Sampler (Reverse) | Yes |
Crossfader
| Crossfader Type | Carbon Rail with P-Lock Fader Cap |
|---|---|
| CURVE Assignable | Yes |
| Field Replaceable | Yes |
| Fader Curve | 3 |
Mic
| Mic Connection |
|
|---|---|
| Mic EQ | 2 band |
| Talkover | 3 Position Switch |
MIDI Info
| Assignable Controls | 49 |
|---|---|
| MIDI On/Off | Yes |
| MIDI Start/Stop | Yes |
Sound card
| Connection | USB |
|---|---|
| Stereo Inputs | 4 |
| Stereo Outputs | 4 |
| Sample Rate | 24 bit |
| Frequency | 96 kHz |
Terminals
| Inputs |
|
|---|---|
| Outputs |
|
| USB | 1 USB B port |
| Manufacturer | PIONEER |
|---|
