Neumann BCM 705 Dynamic Studio Microphone
The BCM 705 is Neumann’s first dynamic microphone. The housing and headgrille are identical to those of the BCM 104;
The BCM 705 is Neumann’s first dynamic microphone. The housing and headgrille are identical to those of the BCM 104; only the green logo indicates that this is something new from Neumann. The principle of reduction to the essentials can be seen in the dynamic capsule with a hypercardioid directional characteristic, specifically designed for speech reproduction at close range. Multi-level isolation from structure-borne noise ensures operation free of interference, even in a lively studio environment.
Features
| Dynamic capsule |
| Hypercardioid directional characteristic |
| Characteristic, functionally optimized design* |
| Integrated pop protection |
| Integrated suspension |
| Individual headgrilles for different users |
| Colored rings to identify the replacement headgrilles |
| Easy removal and cleaning of microphone headgrille (with bayonet mount) |
| Mechanical compatibility with standard studio boom arms |
| Multi-level isolation from structure-borne noise |
| No power supply required |
Product Specs
| Acoustical operating principle | Pressure gradient transducer |
| Directional pattern | Hypercardioid |
| Frequency range | 20 Hz ... 20 kHz |
| Sensitivity at 1 kHz into 10 kohm | 1.7 mV/Pa |
| Rated impedance | 200 ohms |
| Rated load impedance | 10 kohms |
| Equivalent noise level, CCIR1) | 32 dB |
| Equivalent noise level, A-weighted1) | 18 dB-A |
| Signal-to-noise ratio, CCIR1) (rel. 94 dB SPL) | 62 dB |
| Signal-to-noise ratio, A-weighted1) (rel. 94 dB SPL) | 76 dB |
| Weight | 500 g |
| Diameter | 64 mm |
| Length | 85 mm |
| Height (without suspension) | 110 mm |
